Description
The Workhorse......
The HQ Stitch 510 is a must-have for every serious quilter. This powerful, high-speed straight stitch machine boasts a nearly 9″ x 6″ workspace, stitching speeds up to 1,600 stitches-per-minute (SPM), an automatic thread cutter, an easy needle threader, and an ergonomic knee presser-foot lift.
Included Accessories
Presser Foot, Hemmer Foot, Knee Lifter, Accessory Box, Dust Cover, Oil and Tools
Optional Accessories
1/4" Seam Foot, Convertible Free-motion Quilting Feet Set, Even-Feed Foot, Darning Foot and Plate, Extension Table, HLx5 Needles
Machine Comparison Chart
|

HQ Stitch 210
|

HQ Stitch 510
|

HQ Stitch 710
|
Maximum Stitch Width |
5 mm |
N/A |
9 mm |
Maximum Stitch Length |
4 mm |
6 mm |
5 mm |
# of Stitches |
20 |
1 |
170 |
Alphabet Stitches |
No |
N/A |
Yes |
Elongate Stitches |
No |
N/A |
Yes |
Mirror Designs |
No |
N/A |
Yes |
Pattern Combinations |
No |
N/A |
Yes |
Stitch Selection |
Easy-navigation Buttons |
N/A |
Direct Selection Buttons |
Speed |
650 SPM |
1,600 SPM |
1,000 SPM |
Free Arm |
Yes |
No |
Yes |
Drop Feed |
Yes |
Optional Cover |
Yes |
Needle Positions |
11 |
1 |
91 |
Needle Up/Down |
Memorized |
Memorized |
Memorized |
Needle Threader |
Built-in |
Built-in |
Built-in |
Thread Cutter |
Manual |
Electronic |
Electronic |
# of Buttonholes |
2 One-Step Buttonholes |
N/A |
10 One-Step Buttonholes |
Start/Stop Button |
Yes |
No |
Yes |
Locking Stitch Button |
Yes |
No |
Yes |
Easy Reverse Button |
Yes |
Yes |
Yes |
Lighting |
Needle-area |
Needle-area |
5 ultra bright LED lamps for shadow-free sewing |
Display |
LED Screen with easy navigation keys |
None |
High resolution LCD touchscreen |
Programmable Features |
No |
N/A |
Yes |
Twin Needle Guard |
No |
No |
Yes |
Straight-Stitch Needle Plate |
Optional Accessory |
N/A |
Yes |
Knee Lift |
No |
Yes |
Yes |
Machine Size (W x H x D) |
13.9″ x 10″ x 6.5″
|
19.6″ x 12.7″ x 7″
|
20.4″ x 12.4″ x 9.1″ |
Machine Weight |
12 lbs |
32 lbs |
26.5 lbs |
Workspace (W x H) |
5.1″ x 4″ |
9″ x 5.5″ |
11″ x 4.7″ |
Foot Pressure Adjustment |
No |
Yes |
Yes |
Extra High Pressure Foot Lift |
No |
No |
Yes |
Hook Type |
Top loading, full rotary hook bobbin |
Vertical, full rotary, industrial hook bobbin |
Top loading, full rotary hook bobbin |
Bobbin Style |
Class 15 |
L-Style |
Class 15 |
Thread Tension Control |
Manual |
Manual |
Automatic |
Feed System |
4 Piece Feed Dog |
Standard |
Dual Feed-Ready |
Bobbin Winding |
Auto-Declutch |
Independent Motor |
Auto-Declutch |
Cover |
Hard Cover |
Dust Cover |
No |
Weight |
38 lbs |
Dimensions |
26 × 18 × 15 in |
