Description
APPLICATIONS
- Three step/two stitch zig-zag
- For sewing elastic and other stretch materials
- For stitching such products as boat and truck covers, tents, awnings, sails, parachutes, tarpaulins and similar products
- Used on such materials as canvas, nylon, vinyl, leather, synthetics and similar materials
- 30" long arm for 30 inches of workspace.
FEATURES
- Large bobbin and horizontal axis transverse rotary hook
- Wide zig-zag
- Upper feed mechanism helps avoid slippage when sewing
- Reverse stitching
- Stitches per minute - 2500*
- Optional: Interchangeable between 1A, 2A & 3A stitches; Additional parts required (not included).
ADDITIONAL INFORMATION
U.S. WARRANTY: 90 Days labor on defects in materials and workmanship.
** Head Only option does not include the table, legs, Servo Motor, and LED Lamp. No assembly or residential charges necessary. *Shipping Due to the weight and shipping methods used for industrial machines they may experience marring and scratches during shipping. This will not affect the operation of the machine.
| Number of Needles | 1 (Single) |
| Feeding Mechanism | Walking Foot |
| Workspace | Long Arm |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 2500 |
| Clearence Under Presser Foot | 25/64" (10mm) |
| Stitch Length | 5 s.p.i. (5mm) |
| Work Space | 30" (765mm) |
| Needle | 135 x 17 |
| Bobbin | Metal 212O34-312 Pre-wound M |
| Bed Size | 7" x 33 1/4" (178mm x 848mm) |
| Needle Bar Stroke | 1-11/32" (34mm) |
| Hook | B79 |
| Zig-Zag Stitch Width | 3/8" (9.5mm) |
