Description
JUKI's unique feed mechanism promises excellent efficiency of feed. The machine is applicable to an extended range of heavy materials for industrial use, such as cargo handling belts and containers, as well as those for general use, such as car seats, sofas and bags, thereby contributing to both improved quality and increased productivity.
Machine Specifications
| Application | Heavy-Weight |
| Max. sewing speed | 2,500 Stitches per Minute |
| Max. stitch length | 9mm (forward/backward) |
| Needle bar stroke | 38mm |
| Lift of the presser foot by hand | 9mm |
| Lift of the presser foot by knee | 18mm |
| Needle Gauge | 4.8mm, 6.4mm, 7.9mm, 9.5mm, 12.7mm (3/16, 1/4, 5/16, 3/8, 1/2) |
| Alternating Vertical Movement | 2.5~6.5mm |
| Thread Take-Up | Slide Type |
| Hook | Vertical-Axis Double-Capacity Hook |
| Needle (at the time of delivery) | 135x17 (Nm160) Nm125~Nm180 |
| Lubrication | Automatic |
| Lubricating Oil | Juki New Defrix Oil No.2 (equivalent to ISO VG32) |
| Bed Size | 517mm x 178mm |
| Weight of the Machine Head | 45kg |
