Description
APPLICATIONS
- For stitching light to medium weight fabric, knits, synthetics, vinyl, canvas, denim and coated and laminated material
- Suitable for attaching pockets to shirts, sewing collars and cuffs, stitching skirts, blouses, dresses, raincoats, general wearing apparel
FEATURES
- High speed - 5000 S.P.M. for light to medium-weight materials
4000 S.P.M. for medium to heavy-weight materials - Horizontal axis transverse rotary hook
- Synchronized drop and needle feed assures even feeding of slippery and difficult to feed materials
- Fully automatic lubrication with recirculating pump
- For light to medium weight fabric
SPECIFICATIONS
| Number of Needles | 1 (Single) |
| Feeding Mechanism | Needle Feed |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 5000 |
| Clearence Under Presser Foot | Hand 7/32" (5.5mm), Knee 9/16" (14mm) |
| Stitch Length | 6.4. s.p.i. (4mm) |
| Work Space | 10" (254mm) |
| Needle | 16 x 257 |
| Bobbin | Pre-Wound L |
| Bed Size | 7" 18 7/8" (178mm x 479mm) |
| Needle Bar Stroke | 1 7/32" (30.7mm) |
| Hook | C-27 |
| Lubrication | Fully Automatic |
