Description
APPLICATIONS
- This machine is appropriate for sewing operations which involve stitching and simultaneous edge trimming. For example stitching and trimming lapels, or stitching and trimming other garment parts, including shirt collars and cuffs
- For men's, ladies', and children's apparel of different weights ranging from light to heavy materials such as cottons, knits, denim, polyester, nylon and sheer fabrics
- This machine is capable of sewing a wide variety of operations by simply changing the gauge set
FEATURES
- Edge trimming device is located alongside the needle
- Edge trimmer is easily engaged or disengaged even during the sewing cycle (push-button control)
- Carbide tipped upper knife and tool steel lower knife
- Trimming margin (distance from the needle to the knife) can easily be changed
- A perfectly balanced mechanical system is used for the knife mechanism assuring vibration -free operation with straight and uniform trimming
- Work area is kept clear (A passage in the machine bed allows for scrap disposal)
- Fully automatic lubrication system
- Stitches per minute - 4000
- Reverse stitching
SPECIFICATIONS
Number of Needles | 1 (Single) |
Feeding Mechanism | Drop Feed |
Workspace | Standard Workspace |
Standard or Full Function | Standard Functions |
Speed, Max (S.P.M.) | 4000 |
Clearence Under Presser Foot | Hand 5/16" (8mm) Knee 15/32" (12mm) |
Stitch Length | 5 s.p.i. (5mm) |
Work Space | 10 1/8" (258mm) |
Needle | 16 x 257 |
Bobbin | Pre-Wound L |
Bed Size | 7" x 18 7/8" (177mm x 477mm) |
Hook | 146 |
Knife Stroke | 13/64" 5mm) |
Lubrication | Fully Automatic |
Trimming Width | 3/8" (9.5mm) |
Gauges | 1/8" standard equipment 1/16", 3/32", 5/32", 3/16", 1/4", 3/8" can be purchased separately |
