Description
APPLICATIONS
- For medium to heavy-duty materials such as leather, canvas, vinyls and various laminated and coated materials
- Designed for sewing operations which require decorative or functional angular stitching such as collars, lapels, pockets, pocket flaps, etc.
- Used for stitching such products as men's, ladies' and childrens' coats, ski wear, jeans, handbags and travelware accessories
- General parallel / two-needle stitching. Top stitching with split bar for angular sewing turns
FEATURES
- Compound feed, walking foot mechanism assures perfect feeding of sewing material
- Large hooks and bobbin cases with their own thread take-up mechanism assure uniform and perfect stitching with minimal bobbin changes
- Easy operation of disengageable right and left needle bars by use of finger-touch lever
- Centra-Lube® semi-automatic lubrication system
- Automatic hook lubrication
- Oil fed take-up
- Stitches per minute - 2200 *
- Reverse stitching
- Various gauge sets available
- Safety clutch protects the hooks from being damaged
- Simple adjustment permits raising and lowering the center foot which allows for sewing different thicknesses of material
SPECIFICATIONS
| Number of Needles | 2 (Double) |
| Feeding Mechanism | Walking Foot |
| Workspace | Standard Workspace |
| Standard or Full Function | Standard Functions |
| Speed, Max (S.P.M.) | 2200 |
| Clearence Under Presser Foot | 11/32" (8.5mm) |
| Stitch Length | 4 s.p.i. (6.5mm) |
| Work Space | 10" (258mm) |
| Needle | 135 x 17 |
| Bobbin | Metal 10408 Pre-Wound U |
| Bed Size | 7" x 20 3/8" (177mm x 518mm) |
| Stitch Type | 301 |
| Needle Bar Stroke | 1 1/4" (32mm) |
| Hook | 16407 |
| Needle Distances | 1/8" (3.2mm)-1"(25.4mm) (1/4") is standard |
