Description
APPLICATIONS
- For sewing light to heavy-weight materials including cottons, knits, polyester, nylon, sheer fabrics and denim
- Suitable for stitching such products as blouses, shirts, men's, ladies and children's apparel, uniforms, overalls, lingerie, etc.
- Heavyweight fabrics such as jeans can be sewn by changing the needle plate, feed dog, foot, stitch regulator, hook and needle bar
FEATURES
- Fully automatic lubrication with recirculating high pressure pump
- Noise and vibration absorbing table mounting
- "Feather-touch" pressure foot lifter
- Ultra high speed – 5500 S.P.M.*
SPECIFICATIONS
Number of Needles | 1 (Single) |
Feeding Mechanism | Drop Feed |
Workspace | Standard Workspace |
Standard or Full Function | Standard Functions |
Speed, Max (S.P.M.) | 5500 |
Speed, Max (S.P.M.) | 5500 |
Clearence Under Presser Foot | 1/4" (6mm) |
Clearence Under Presser Foot | 1/4" (6mm) |
Stitch Length | 5 s.p.i. (5mm) |
Stitch Length | 5 s.p.i. (5mm) |
Work Space | 10" (258mm) |
Work Space | 10" (258mm) |
Needle | 16 x 257 |
Needle | 16 x 257 |
Bobbin | Metal 22T4-017 Pre-wound L |
Bobbin | Metal 22T4-017 Pre-wound L |
Bed Size | 7" x 18 7/8" (177mm x 477mm) |
Bed Size | 7" x 18 7/8" (177mm x 477mm) |
Stitch Type | 301 |
Stitch Type | 301 |
Needle Bar Stroke | 1 1/4" (31.8mm) |
Needle Bar Stroke | 1 1/4" (31.8mm) |
Hook | 22T4-011D |
Hook | 22T4-011D |
