Description
APPLICATIONS
- For sewing light to heavy-weight materials including cottons, knits, polyester, nylon, sheer fabrics and denim
- Suitable for stitching such products as blouses, shirts, men's, ladies and children's apparel, uniforms, overalls, lingerie, etc.
- Heavyweight fabrics such as jeans can be sewn by changing the needle plate, feed dog, foot, stitch regulator, hook and needle bar
FEATURES
Convenient Thread Wiper
Top thread is taken up as soon as thread trimming is done.
User-Friendly Easy Operation
One-touch button serves as reverse stitch control.
Reliable Thread Trimmer
Thread cutters are fast, accurate and promote speed and sewing quality.
Built-in Synchronizer
Needle position is easily adjusted by three screws.
Reliable Accurate Stitch Length Dial
Push-button release on the stitch length control is fixed to prevent change in stitch length by vibration.
• For sewing light to heavy-weight materials including cottons, knits, polyester, nylon, sheer fabrics and denim
• Suitable for stitching such products as blouses, shirts, men's, ladies and children's apparel, uniforms, overalls, lingerie, etc.
• Heavyweight fabrics such as jeans can be sewn by changing the needle plate, feed dog, foot, stitch regulator, hook and needle bar
SPECIFICATIONS
| Number of Needles | 1 (Single) |
| Feeding Mechanism | Drop Feed |
| Workspace | Standard Workspace |
| Standard or Full Function | Auto Trimming, Backtack, Reverse |
| Speed, Max (S.P.M.) | 5500 |
| Speed, Max (S.P.M.) | 3000 |
| Clearence Under Presser Foot | 1/4" (6mm) |
| Clearence Under Presser Foot | 1/4" (6mm) |
| Stitch Length | 4mm |
| Stitch Length | 5 s.p.i. (5mm) |
| Work Space | 10" (258mm) |
| Needle | 16 x 257 |
| Needle | 16 x 257 |
| Bobbin | Metal 22T4-017 Pre-wound L |
| Bed Size | 7" x 18 7/8" (177mm x 477mm) |
| Stitch Type | 301 |
| Needle Bar Stroke | 1 1/4" (31.8mm) |
| Needle Bar Stroke | 35mm |
| Hook | Double-Capacity Auto-Lubricating Full-Rotary Hook |
| Hook | 22T4-011D |
