Juki DLU-5490N 1-needle, Bottom and Variable Top-feed, Lockstitch Machine


Call 1-800-487-7397 for details.


 1-needle, Bottom and Variable Top-feed, Lockstitch Machine

With its bottom and variable top-feed mechanism, the machine widely adapts to diversified applications and helps promote the production of upgraded-quality products while increasing efficiency.

  • With its bottom and variable top-feed mechanism, the machine widely adapts to diversified applications and helps promote the production of upgraded-quality products while increasing efficiency.
  • Ideally balanced top feed and bottom feed: the top feed motion ideally synchronized with the bottom feed motion to uniformly feed the upper and lower cloths, assuring attractive stitches and uniform gathering stitches. This leads to a higher value of finished products.
  • Durability of the walking foot has been dramatically improved: The walking foot provides stable feed at all times, assuring high quality. It also eliminates the need for proficiency.
  • The maximum top feed amount is 8mm. The top feed amount has been increased to assure stable gathering stitches.
  • Sure thread trimming mechanism: The machine comes with a thread trimming mechanism that performs speedy and sure thread trimming to achieve highly efficient sewing work.
  • Higher lift of the presser foot. The large lift of the presser foot enables the operator to easily set or remove materials and sew overlapping sections without any difficulty.
Model name DLU-5490N-7, 5490N
Max. sewing speed 4,500sti/min
Max. stitch length 5mm
Max. top-feed amount 8mm
Presser foot By knee: 13mm
Needle DB×1 (#14), 134 (Nm75)
